MET-18
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Audio Transformers
Description
Audio Transformers / Signal Transformers Pri10KohmCT Sec4Kohm 40mW@300Hz
PDF
/
Buying Options
Total Price: USD $19.11
Unit Price: USD $19.107947
≥1 USD $19.107947
≥200 USD $7.62401
≥550 USD $7.369308
≥1100 USD $7.243269
Inventory: 4842
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 25 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Number of Pins 5
Technical
Operating Temperature -20°C~85°C
Packaging Bulk
Published 2006
Series MET
Size / Dimension 0.409Lx0.310W 10.40mmx7.87mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
Reach Compliance Code unknown
Termination Style PC Pin
Voltage - Isolation 500VRMS @ 30 Seconds
Current 1mA
Frequency Range 300Hz~100kHz
Transformer Type Data/Voice Coupling
Turns Ratio - Primary:Secondary 1:0.02
Impedance - Primary (Ω) 10kCT
Frequency Response ±2dB
Impedance - Secondary (Ω) 4
DC Resistance (DCR) - Primary 1.2kOhm
DC Resistance (DCR) - Secondary 1Ohm
Power Level 40mW
Dimensions
Height 11.8mm
Height Seated (Max) 0.465 11.80mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
