MET-10
RoHS
RoHS compliant
RoHS compliantPackage DIP
Category Transformers / Audio Transformers
Description
Audio Transformers / Signal Transformers Pri 10KohmCT 40mW Sec 4KohmCT
PDF
/
Buying Options
Total Price: USD $21.84
Unit Price: USD $21.837466
≥1 USD $21.837466
≥200 USD $8.713717
≥550 USD $8.422254
≥1100 USD $8.279147
Inventory: 2393
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 0.465 11.80mm
Height 11.8mm
Technical
Power Level 40mW
DC Resistance (DCR) - Secondary 500Ohm
DC Resistance (DCR) - Primary 1kOhm
Impedance - Secondary (Ω) 4kCT
Frequency Response ±2dB
Impedance - Primary (Ω) 10kCT
Turns Ratio - Primary:Secondary 1.58:1
Transformer Type TELECOM TRANSFORMER
Frequency Range 300Hz~100kHz
Voltage - Isolation 500VRMS @ 30 Seconds
Termination Style PC Pin
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.409Lx0.310W 10.40mmx7.87mm
Series MET
Published 2013
Packaging Bulk
Operating Temperature -20°C~85°C
Physical
Number of Pins 6
Package / Case DIP
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 25 Weeks
