T6027NL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Audio Transformers
Description
TRANSFORMER AUDIO 1500VRMS SMD
PDF
/
Inventory: 6347
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Technical
Packaging Tube
Published 2009
Size / Dimension 0.530Lx0.516W 13.46mmx13.11mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Termination Style Gull Wing
Voltage - Isolation 1500Vrms
DC Resistance (DCR) 55Ohm
Lead/Base Style Gull Wing
Insertion Loss 1.2dB @ 200Hz, 1dB @ 1kHz, 1dB @ 20kHz, 1.7dB @ 100kHz
Transformer Type Data/Voice Coupling
Turns Ratio - Primary:Secondary 1:2
Return Loss 18dB @ 200Hz, 18dB @ 1kHz, 18dB @ 10kHz
Impedance - Primary (Ω) 600
Impedance - Secondary (Ω) 2.4k
DC Resistance (DCR) - Primary 55Ohm
DC Resistance (DCR) - Secondary 390Ohm
Dimensions
Height Seated (Max) 0.485 12.32mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
