RoHS
/
Package 600
Category Transformers / Audio Transformers
Description Audio Transformers / Signal Transformers 150/600 1200/4800
PDF
/
Inventory: 6462
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Height Seated (Max) 1.650 41.91mm
Height 21.59mm

Technical

Power Level 15dB
DC Resistance (DCR) - Secondary 570Ohm
DC Resistance (DCR) - Primary 69Ohm
Impedance - Secondary (Ω) 4.8k 1.2k/1.2k
Frequency Response ±0.5dB
Impedance - Primary (Ω) 600 150/150
Transformer Type Broadcast Quality
Insertion Loss (dB) 1 dB
Frequency Range 20Hz~20kHz
Termination Style Solder Lug
Shielding Shielded
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Size / Dimension 1.700Lx1.200W 43.18mmx30.48mm
Series 850
Published 2015
Packaging Bulk

Physical

Weight 0.4lb 181.44g
Package / Case 600
Mounting Type Chassis Mount
Mount Chassis Mount
