RoHS
/
Package 600
Category Transformers / Audio Transformers
Description
TRANSF AUDIO 150/600 150/600 IMP
PDF
/
Inventory: 2290
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Package / Case 600
Weight 0.4lb 181.44g
Technical
Packaging Bulk
Series 850
Size / Dimension 1.700Lx1.200W 43.18mmx30.48mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
ECCN Code EAR99
Shielding Shielded
Termination Style Solder Lug
DC Resistance (DCR) 71Ohm
Frequency Range 20Hz~20kHz
Insertion Loss (dB) 1 dB
Transformer Type Broadcast Quality
Impedance - Primary (Ω) 600 150/150
Frequency Response ±0.5dB
Impedance - Secondary (Ω) 600 150/150
DC Resistance (DCR) - Primary 71Ohm
DC Resistance (DCR) - Secondary 71Ohm
Power Level 15dB
Dimensions
Height 21.59mm
Height Seated (Max) 1.650 41.91mm
Compliance
RoHS Status RoHS Compliant
