RoHS
/
Package /
Category Transformers / Audio Transformers
Description
Audio Transformers / Signal Transformers 50/200 600/2400
PDF
/
Buying Options
Total Price: USD $29.03
Unit Price: USD $29.0312
≥1 USD $29.0312
Inventory: 110
Minimum: 1
-
+
Technical Details
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Weight 0.5lb 226.8g
Technical
Packaging Bulk
Series 800
Size / Dimension 1.752Lx1.252W 44.50mmx31.80mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pin
Shielding Shielded
Termination Style Solder Lug
Current 600μA
Frequency Range 50Hz~15kHz
Insertion Loss 1dB
Insertion Loss (dB) 1 dB
Transformer Type Broadcast Quality
Impedance - Primary (Ω) 200 50/50
Frequency Response ±0.5dB
Impedance - Secondary (Ω) 2.4k 600/600
Power Level 15dB
Dimensions
Height 65.024mm
Height Seated (Max) 2.559 65.00mm
Length 44.45mm
Width 31.75mm
Compliance
RoHS Status RoHS Compliant
