RoHS
/
Package /
Category Transformers / Audio Transformers
Description
TRANSFR AUDIO 7.5/30 10K/40K IMP
PDF
/
Inventory: 5830
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 31.75mm
Length 44.45mm
Height Seated (Max) 2.559 65.00mm
Height 65.024mm
Technical
Power Level 15dB
Impedance - Secondary (Ω) 40k 10k/10k
Frequency Response ±0.5dB
Impedance - Primary (Ω) 30 7.5/7.5
Transformer Type Broadcast Quality
Insertion Loss (dB) 1 dB
Insertion Loss 1dB
Frequency Range 50Hz~15kHz
Current 1.6mA
Termination Style Solder Lug
Shielding Shielded
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Size / Dimension 1.752Lx1.252W 44.50mmx31.80mm
Series 800
Packaging Bulk
Physical
Weight 0.5lb 226.8g
Mounting Type Chassis Mount
Mount Chassis Mount
