RoHS
/
Package 600
Category Transformers / Audio Transformers
Description
Audio Transformers / Signal Transformers 50/200 125/500
PDF
/
Buying Options
Total Price: USD $186.82
Unit Price: USD $186.824
≥1 USD $186.824
Inventory: 86
Minimum: 1
-
+
Technical Details
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Package / Case 600
Weight 0.5lb 226.8g
Technical
Packaging Bulk
Series 800
Size / Dimension 1.752Lx1.252W 44.50mmx31.80mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
Shielding Shielded
Termination Style Solder Lug
Current 800μA
Frequency Range 50Hz~15kHz
Insertion Loss 1dB
Insertion Loss (dB) 1 dB
Transformer Type Broadcast Quality
Impedance - Primary (Ω) 200 50/50
Frequency Response ±0.5dB
Impedance - Secondary (Ω) 600 150/150
Power Level 15dB
Dimensions
Height 65.024mm
Height Seated (Max) 2.559 65.00mm
Length 44.45mm
Width 31.75mm
Compliance
RoHS Status RoHS Compliant
