1750V image
Favorite
1750V image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Audio Transformers
Description TRANSFORMER TUBE GUITAR AMP
PDF
/
Buying Options
Total Price: USD $126.57
Unit Price: USD $126.5704
≥1 USD $126.5704
≥10 USD $122.3552
≥100 USD $113.916704
≥500 USD $105.478384
Inventory: 95
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Height Seated (Max) 3.843 97.61mm

Technical

Power Level 30W
DC Resistance (DCR) - Secondary 720mOhm
DC Resistance (DCR) - Primary 138Ohm
Impedance - Secondary (Ω) 8 16
Frequency Response ±1dB
Impedance - Primary (Ω) 4kCT
Turns Ratio - Primary:Secondary 15.93:1
Transformer Type Push-Pull Audiophile, Ultra-Linear - Tube Output
Insertion Loss (dB) 1 dB
Frequency Range 70Hz~15kHz
Termination Style Wire Leads
Termination Wire Leads
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Size / Dimension 3.125Lx3.325W 79.38mmx84.46mm
Series 1750
Packaging Bulk

Physical

Weight 0.625lb 283.5g
Mounting Type Chassis Mount
Mount Chassis Mount

Supply Chain

Factory Lead Time 4 Weeks
