1750Q
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Audio Transformers
Description
Audio Transformers / Signal Transformers Marshall/JTM 45 Primary Ohms 7371 CT
PDF
/
Buying Options
Total Price: USD $111.7
Unit Price: USD $111.6984
≥1 USD $111.6984
≥10 USD $107.97248
≥100 USD $100.52592
≥500 USD $93.079536
Inventory: 70
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 3.813 96.85mm
Technical
Power Level 50W
DC Resistance (DCR) - Secondary 120mOhm 190mOhm 270mOhm
DC Resistance (DCR) - Primary 81.61Ohm 78.63Ohm
Impedance - Secondary (Ω) 4 8 16
Frequency Response ±1dB
Impedance - Primary (Ω) 7.371kCT
Turns Ratio - Primary:Secondary 21.46:1
Transformer Type Push-Pull Audiophile, Ultra-Linear - Tube Output
Insertion Loss (dB) 1 dB
Frequency Range 50Hz~12kHz
Termination Style Wire Leads
Termination Wire Leads
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Size / Dimension 3.125Lx3.280W 79.38mmx83.31mm
Series 1750
Published 2008
Packaging Bulk
Physical
Weight 0.625lb 283.5g
Mounting Type Chassis Mount
Mount Chassis Mount
Supply Chain
Factory Lead Time 4 Weeks
