1650FA
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Audio Transformers
Description
Audio Transformers / Signal Transformers PUSHPULL 25W 7,600CT
PDF
/
Buying Options
Total Price: USD $131.98
Unit Price: USD $131.9824
≥1 USD $131.9824
≥10 USD $127.58768
≥100 USD $118.788032
≥500 USD $109.989088
Inventory: 18
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Weight 4lbs 1.8kg
Technical
Packaging Bulk
Published 2013
Series A
Size / Dimension 3.500Lx2.500W 88.90mmx63.50mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Wire Leads
Termination Style Wire Leads
Voltage - Isolation 2000V @ 1 Second
Current 128mA
Frequency Range 30Hz~30kHz
Insertion Loss (dB) 1 dB
Transformer Type Push-Pull Audiophile, Ultra-Linear - Tube Output
Impedance - Primary (Ω) 7.6kCT
Frequency Response ±1dB
Impedance - Secondary (Ω) 4 8 16
DC Resistance (DCR) - Primary 92.16Ohm 102.8Ohm
DC Resistance (DCR) - Secondary 210mOhm 239mOhm 309mOhm
Power Level 25W
Dimensions
Height Seated (Max) 3.060 77.72mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
