149S image
Favorite
149S image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Audio Transformers
Description TRANSFORMR AUDIO 600CT/150CT IMP
PDF
/
Buying Options
Total Price: USD $22.59
Unit Price: USD $22.5896
≥1 USD $22.5896
≥10 USD $19.93112
≥100 USD $19.267072
≥500 USD $17.273872
≥1000 USD $16.609472
Inventory: 89
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 4 Weeks

Physical

Mount Through Hole
Mounting Type Through Hole
Weight 0.063lb 28.58g

Technical

Packaging Bulk
Series 149
Size / Dimension 1.060Lx0.820W 26.92mmx20.83mm
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pin
ECCN Code EAR99
Power Rating 1W
Shielding Unshielded
Termination Style PC Pin
DC Resistance (DCR) 53Ohm
Current 4mA
Max DC Current 4mA
Frequency Range 200Hz~15kHz
Insertion Loss 0.5dB
Insertion Loss (dB) 1 dB
Transformer Type Economical Open Type
Impedance - Primary (Ω) 600CT
Frequency Response ±1dB
Impedance - Secondary (Ω) 150CT
DC Resistance (DCR) - Primary 53Ohm
DC Resistance (DCR) - Secondary 17Ohm
Power Level 1000mW

Dimensions

Height 20.828mm
Height Seated (Max) 0.820 20.83mm

Compliance

RoHS Status ROHS3 Compliant
