Category Transformers / Audio Transformers
Description
TRANSFORM AUDIO 3K TO 250/1K IMP
PDF
/
Buying Options
Total Price: USD $13.55
Unit Price: USD $13.552
≥1 USD $13.552
Inventory: 37
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 0.038lb 17.24g
Technical
Packaging Bulk
Series 148
Size / Dimension 0.820Lx0.680W 20.83mmx17.27mm
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pin
ECCN Code EAR99
Shielding Unshielded
Termination Style PC Pin
Current 7.5mA
Frequency Range 200Hz~15kHz
Insertion Loss 0.5dB
Insertion Loss (dB) 1 dB
Transformer Type Economical Open Type
Impedance - Primary (Ω) 3k
Frequency Response ±1dB
Impedance - Secondary (Ω) 1k 250/250
DC Resistance (DCR) - Primary 480Ohm
DC Resistance (DCR) - Secondary 107Ohm
Power Level 75mW
Dimensions
Height 17.5mm
Height Seated (Max) 0.690 17.53mm
Compliance
RoHS Status ROHS3 Compliant
