RoHS
RoHS compliant
RoHS compliantPackage 125
Category Transformers / Audio Transformers
Description
TRANSF AUDIO 1.5K TO 125/500 IMP
PDF
/
Buying Options
Total Price: USD $58.86
Unit Price: USD $58.863872
≥1 USD $58.863872
≥200 USD $23.487781
≥500 USD $22.702667
≥1000 USD $22.315361
Inventory: 4749
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.690 17.53mm
Height 17.5mm
Technical
Power Level 75mW
DC Resistance (DCR) - Secondary 58Ohm
DC Resistance (DCR) - Primary 220Ohm
Impedance - Secondary (Ω) 500 125/125
Frequency Response ±1dB
Impedance - Primary (Ω) 1.5k
Transformer Type Economical Open Type
Insertion Loss (dB) 1 dB
Insertion Loss 0.5dB
Frequency Range 200Hz~15kHz
Current 11.6mA
Termination Style PC Pin
Shielding Unshielded
ECCN Code EAR99
Termination PC Pin
Part Status Active
Size / Dimension 0.820Lx0.680W 20.83mmx17.27mm
Series 148
Packaging Bulk
Physical
Weight 0.038lb 17.24g
Package / Case 125
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 4 Weeks
