RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Audio Transformers
Description
Audio Transformers / Signal Transformers INPUT
PDF
/
Buying Options
Total Price: USD $18.61
Unit Price: USD $18.612
≥1 USD $18.612
≥10 USD $16.4252
≥100 USD $15.877664
≥500 USD $14.235056
≥1000 USD $13.68752
Inventory: 49
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 0.038lb 17.24g
Technical
Packaging Bulk
Series 148
Size / Dimension 0.820Lx0.680W 20.83mmx17.27mm
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pin
ECCN Code EAR99
Power Rating 12mW
Shielding Unshielded
Termination Style PC Pin
DC Resistance (DCR) 1.76kOhm
Frequency Range 200Hz~15kHz
Insertion Loss 0.5dB
Insertion Loss (dB) 1 dB
Transformer Type Economical Open Type
Impedance - Primary (Ω) 50k
Frequency Response ±1dB
Impedance - Secondary (Ω) 1k 250/250
DC Resistance (DCR) - Primary 1.76kOhm
DC Resistance (DCR) - Secondary 25.4Ohm
Dimensions
Height 17.53mm
Height Seated (Max) 0.690 17.53mm
Compliance
RoHS Status ROHS3 Compliant
