148B image
Favorite
148B image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Audio Transformers
Description TRANSF AUDIO 150 TO 400/1.6K IMP
PDF
/
Buying Options
Total Price: USD $22.59
Unit Price: USD $22.5896
≥1 USD $22.5896
≥10 USD $19.93112
≥100 USD $16.609472
Inventory: 89
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Height Seated (Max) 0.690 17.53mm
Height 17.526mm

Technical

DC Resistance (DCR) - Secondary 200Ohm
DC Resistance (DCR) - Primary 11.3Ohm
Impedance - Secondary (Ω) 1.6k 400/400
Frequency Response ±1dB
Impedance - Primary (Ω) 150
Transformer Type Economical Open Type
Insertion Loss (dB) 1 dB
Insertion Loss 0.5dB
Frequency Range 200Hz~15kHz
Current 3.8mA
Termination Style PC Pin
Shielding Unshielded
Power Rating 300mW
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Size / Dimension 0.820Lx0.680W 20.83mmx17.27mm
Series 148
Packaging Bulk

Physical

Weight 0.038lb 17.24g
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 4 Weeks
