RoHS
RoHS compliant
RoHS compliantPackage 600
Category Transformers / Audio Transformers
Description
TRANS AUDIO 150/600-600/2.4K IMP
PDF
/
Inventory: /
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.690 17.53mm
Height 20.828mm
Technical
DC Resistance (DCR) - Secondary 300Ohm
DC Resistance (DCR) - Primary 45Ohm
Impedance - Secondary (Ω) 2.4k 600/600
Frequency Response ±1dB
Impedance - Primary (Ω) 600 150/150
Transformer Type Economical Open Type
Insertion Loss (dB) 1 dB
Insertion Loss 0.5dB
Frequency Range 200Hz~15kHz
Max DC Current 1.9mA
Current 1.9mA
DC Resistance (DCR) 300Ohm
Termination Style PC Pin
Shielding Unshielded
Power Rating 300mW
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Size / Dimension 0.820Lx0.680W 20.83mmx17.27mm
Series 148
Packaging Bulk
Physical
Weight 0.038lb 17.24g
Package / Case 600
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 4 Weeks
