RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Audio Transformers
Description
Audio Transformers / Signal Transformers OUTPUT
PDF
/
Buying Options
Total Price: USD $22.19
Unit Price: USD $22.1936
≥1 USD $22.1936
≥10 USD $19.5844
≥100 USD $16.320568
Inventory: 54
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Weight 0.031lb 14.06g
Technical
Packaging Bulk
Series 146
Size / Dimension 1.630Lx0.880W 41.40mmx22.35mm
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Wire Leads
ECCN Code EAR99
Power Rating 700mW
Shielding Unshielded
Termination Style Wire Leads
DC Resistance (DCR) 2.4Ohm
Current 20mA
Max DC Current 20mA
Frequency Range 150Hz~15kHz
Insertion Loss (dB) 1 dB
Transformer Type Economical Open Type
Impedance - Primary (Ω) 48CT
Frequency Response ±1dB
Impedance - Secondary (Ω) 8
DC Resistance (DCR) - Primary 2.4Ohm
DC Resistance (DCR) - Secondary 700mOhm
Dimensions
Height 20.574mm
Height Seated (Max) 0.810 20.57mm
Compliance
RoHS Status ROHS3 Compliant
