RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Audio Transformers
Description
Audio Transformers / Signal Transformers DRIVER
PDF
/
Buying Options
Total Price: USD $13.3
Unit Price: USD $13.2968
≥1 USD $13.2968
Inventory: 89
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Weight 0.088lb 39.92g
Technical
Packaging Bulk
Series 145
Size / Dimension 1.630Lx0.880W 41.40mmx22.35mm
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Wire Leads
ECCN Code EAR99
Power Rating 100mW
Shielding Unshielded
Current Rating 45mA
Termination Style Wire Leads
DC Resistance (DCR) 19Ohm
Current 45mA
Max DC Current 45mA
Frequency Range 150Hz~15kHz
Insertion Loss (dB) 1 dB
Transformer Type Economical Open Type
Impedance - Primary (Ω) 100
Frequency Response ±1dB
Impedance - Secondary (Ω) 200CT
DC Resistance (DCR) - Primary 14Ohm
DC Resistance (DCR) - Secondary 19Ohm
Dimensions
Height 20.57mm
Height Seated (Max) 0.810 20.57mm
Compliance
RoHS Status ROHS3 Compliant
