125DSE image
Favorite
125DSE image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Audio Transformers
Description Audio Transformers / Signal Transformers Audio/Universal/1End 70mA/Audio Power 10W
PDF
/
Buying Options
Total Price: USD $61.49
Unit Price: USD $61.4856
≥1 USD $61.4856
≥10 USD $59.43784
≥100 USD $55.338624
≥500 USD $51.239232
Inventory: 29
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Height Seated (Max) 2.630 66.80mm
Height 66.802mm

Technical

DC Resistance (DCR) - Secondary 590mOhm
DC Resistance (DCR) - Primary 115Ohm
Impedance - Secondary (Ω) 4~32
Frequency Response ±1dB
Impedance - Primary (Ω) 2.5k~10k
Transformer Type General Purpose
Insertion Loss (dB) 1 dB
Frequency Range 100Hz~15kHz
Max DC Current 70mA
Current 70mA
Voltage - Isolation 1500V @ 1 Second
Termination Style Wire Leads
Current Rating 70mA
Shielding Unshielded
Power Rating 10W
Termination Wire Leads
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Size / Dimension 4.000Lx2.100W 101.60mmx53.34mm
Series 125SE
Published 2015
Packaging Bulk

Physical

Weight 2lbs 907.2g
Mounting Type Chassis Mount
Mount Chassis Mount

Supply Chain

Factory Lead Time 4 Weeks
