RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Audio Transformers
Description
Audio Transformers / Signal Transformers 100K ct 1K ct
PDF
/
Buying Options
Total Price: USD $28.36
Unit Price: USD $28.3624
≥1 USD $28.3624
≥10 USD $25.02456
≥100 USD $20.853448
Inventory: 191
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 0.02lb 9.07g
Technical
Packaging Bulk
Series 107
Size / Dimension 0.630Lx0.586W 16.00mmx14.88mm
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pin
ECCN Code EAR99
Power Rating 150mW
Shielding Unshielded
Termination Style PC Pin
Voltage - Isolation 500Vrms
Frequency Range 300Hz~50kHz
Insertion Loss (dB) 1.5 dB
Transformer Type Miniature Epoxy Potted
Turns Ratio - Primary:Secondary 10:1
Impedance - Primary (Ω) 100kCT
Frequency Response ±1.5dB
Impedance - Secondary (Ω) 1kCT
DC Resistance (DCR) - Primary 3.66kOhm
DC Resistance (DCR) - Secondary 75Ohm
Dimensions
Height 16mm
Height Seated (Max) 0.630 16.00mm
Compliance
RoHS Status ROHS3 Compliant
