RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Audio Transformers
Description
Audio Transformers / Signal Transformers OUTPUT
PDF
/
Buying Options
Total Price: USD $79.18
Unit Price: USD $79.180999
≥1 USD $79.180999
≥200 USD $31.593626
≥500 USD $30.538054
≥1000 USD $30.016833
Inventory: 5768
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 0.09lb 40.82g
Technical
Packaging Bulk
Series 106
Size / Dimension 1.080Lx0.880W 27.43mmx22.35mm
Part Status Active
Termination PC Pin
ECCN Code EAR99
Shielding Unshielded
Termination Style PC Pin
Voltage - Isolation 200V
Current 10mA
Frequency Range 170Hz
Insertion Loss (dB) 1 dB
Transformer Type Miniature Epoxy Potted
Impedance - Primary (Ω) 500CT
Frequency Response -1dB
Impedance - Secondary (Ω) 3.2
DC Resistance (DCR) - Primary 26Ohm
DC Resistance (DCR) - Secondary 300mOhm
Power Level 1.5W
Dimensions
Height 24.1mm
Height Seated (Max) 0.950 24.13mm
Compliance
RoHS Status ROHS3 Compliant
