RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Audio Transformers
Description
Audio Transformers / Signal Transformers INPUT
PDF
/
Buying Options
Total Price: USD $32.43
Unit Price: USD $32.428
≥1 USD $32.428
≥10 USD $28.61056
≥100 USD $23.842016
Inventory: 53
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 0.09lb 40.82g
Technical
Packaging Bulk
Series 106
Size / Dimension 1.080Lx0.880W 27.43mmx22.35mm
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pin
ECCN Code EAR99
Shielding Unshielded
Termination Style PC Pin
Voltage - Isolation 200V
Frequency Range 60Hz
Insertion Loss (dB) 1 dB
Transformer Type Miniature Epoxy Potted
Impedance - Primary (Ω) 50k
Frequency Response -1dB
Impedance - Secondary (Ω) 1.5kCT
DC Resistance (DCR) - Primary 2.4kOhm
DC Resistance (DCR) - Secondary 52Ohm
Power Level 10mW
Dimensions
Height 24.1mm
Height Seated (Max) 0.950 24.13mm
Compliance
RoHS Status ROHS3 Compliant
