RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Audio Transformers
Description
TRANSFORMER AUDIO 2500CT/50CT
PDF
/
Buying Options
Total Price: USD $19.62
Unit Price: USD $19.6152
≥1 USD $19.6152
≥10 USD $17.3052
≥100 USD $14.420736
Inventory: 99
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 0.01lb 4.54g
Technical
Packaging Bulk
Series 101
Size / Dimension 0.450Lx0.450W 11.43mmx11.43mm
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pin
ECCN Code EAR99
Power Rating 100mW
Shielding Unshielded
Termination Style PC Pin
Physical Dimension L11.43XB11.43XH12.19 (mm)
Frequency Range 200Hz~100kHz
Operating Frequency-Max 100kHz
Operating Frequency-Min 0.3kHz
Insertion Loss (dB) 0.5 dB
Transformer Type Miniature Epoxy Potted
Impedance - Primary (Ω) 2.5kCT
Frequency Response ±0.5dB
Impedance - Secondary (Ω) 50CT
DC Resistance (DCR) - Primary 150.7Ohm
DC Resistance (DCR) - Secondary 4.9Ohm
Dimensions
Height 12.192mm
Height Seated (Max) 0.480 12.19mm
Length 11.43mm
Width 11.43mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
