TDA7500A
RoHS
RoHS compliant
RoHS compliantPackage 100-LQFP Exposed Pad
Category Integrated Circuits (ICs) / Audio Special Purpose
Description
TDA7500 e4 100-LQFP Exposed Pad CMOS audio circuit 14mm 3.3V AM FM 45MHz
PDF
/
Buying Options
Total Price: USD $46.08
Unit Price: USD $46.077538
≥1 USD $46.077538
≥180 USD $18.385852
≥540 USD $17.771414
≥990 USD $17.468135
Inventory: 1531
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 100-LQFP Exposed Pad
Surface Mount YES
Number of Pins 100
Technical
Operating Temperature -40°C~125°C TJ
Packaging Tray
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 100
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Applications Digital Audio Interfacing
HTS Code 8542.39.00.01
Subcategory Other Consumer ICs
Technology CMOS
Voltage - Supply 3.15V~3.45V
Terminal Position QUAD
Terminal Form GULL WING
Terminal Pitch 0.5mm
Base Part Number TDA7500
Function Fully Integrated Processor
Operating Supply Voltage 3.3V
Supply Voltage-Max (Vsup) 3.45V
Supply Voltage-Min (Vsup) 3.15V
Number of Channels 6
Interface I2C, SPI
RAM Size 34.5kB
Supply Current-Max 490mA
Data Bus Width 24b
Specifications AM, FM
Max Frequency 45MHz
Consumer IC Type CONSUMER CIRCUIT
Dimensions
Length 14mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
