TDA7440D
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Audio Special Purpose
Description
TDA7440 e4 28-SOIC (0.295 7.50mm Width) BICMOS audio IC 7.6mm 10mA 9V 90dB
PDF
/
Buying Options
Total Price: USD $2.18
Unit Price: USD $2.18405
≥1 USD $2.18405
≥10 USD $1.7917
≥100 USD $1.73565
≥500 USD $1.6796
≥1000 USD $1.62355
Inventory: 1628
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 7.6mm
Length 18.1mm
Height 2.35mm
Technical
Channel Separation 90 dB
Harmonic Distortion 0.01%
Number of Bands 2
Consumer IC Type TONE CONTROL CIRCUIT
Gain 30 dB
Nominal Supply Current 10mA
Interface I2C
Number of Channels 2
Supply Voltage-Min (Vsup) 6V
Power Supplies 9V
Qualification Status Not Qualified
Function Audio Tone Processor
Base Part Number TDA7440
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 6V~10.2V
Technology BICMOS
Subcategory Other Consumer ICs
Applications Consumer Audio
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 28
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e4
Packaging Tube
Operating Temperature 0°C~70°C TA
Physical
Number of Pins 28
Package / Case 28-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
