TDA7437N
RoHS
RoHS compliant
RoHS compliantPackage 44-LQFP Exposed Pad
Category Integrated Circuits (ICs) / Audio Special Purpose
Description
TDA7437 e4 44-LQFP Exposed Pad BICMOS audio circuit 10mm 9V 95dB -40C~85C TA
PDF
/
Buying Options
Total Price: USD $4.03
Unit Price: USD $4.028
≥1 USD $4.028
≥10 USD $3.30505
≥100 USD $3.2015
≥500 USD $3.09795
≥1000 USD $2.99535
Inventory: 1361
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 10mm
Length 10mm
Height Seated (Max) 1.6mm
Technical
Channel Separation 95 dB
Harmonic Distortion 0.01%
Number of Bands 3
Consumer IC Type TONE CONTROL CIRCUIT
Supply Current-Max 13mA
Interface I2C
Number of Channels 2
Supply Voltage-Min (Vsup) 6V
Power Supplies 9V
Qualification Status Not Qualified
Function Audio Tone Processor
Base Part Number TDA7437
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.8mm
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position QUAD
Voltage - Supply 6V~10.2V
Technology BICMOS
Subcategory Audio Control ICs
Applications Automotive Audio, Consumer Audio
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 44
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e4
Packaging Tray
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 44
Surface Mount YES
Package / Case 44-LQFP Exposed Pad
Mounting Type Surface Mount
