TDA7318D013TR
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Audio Special Purpose
Description
TDA7318 e4 28-SOIC (0.295 7.50mm Width) BICMOS audio circuit 7.5mm 10V 1.25dB -40C~85C TA
PDF
/
Buying Options
Total Price: USD $2.77
Unit Price: USD $2.76545
≥1 USD $2.76545
≥10 USD $2.26955
≥100 USD $2.1983
≥500 USD $2.12705
≥1000 USD $2.05675
Inventory: 1348
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.5mm
Length 17.9mm
Technical
Channel Separation 103 dB
Harmonic Distortion 0.09%
Number of Bands 2
Consumer IC Type TONE CONTROL CIRCUIT
Specifications 1.25dB
Supply Current-Max 11mA
Interface I2C
Number of Channels 2
Supply Voltage-Min (Vsup) 6V
Supply Voltage-Max (Vsup) 10V
Qualification Status Not Qualified
Function Audio Tone Processor
Base Part Number TDA7318
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 6V~10V
Technology BICMOS
Applications Automotive Audio, Consumer Audio
Terminal Finish NICKEL PALLADIUM GOLD
ECCN Code EAR99
Number of Terminations 28
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 28
Surface Mount YES
Package / Case 28-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
