STA308
RoHS
RoHS compliant
RoHS compliantPackage 64-LQFP
Category Integrated Circuits (ICs) / Audio Special Purpose
Description
STA308 e4 DDX? 64-LQFP audio IC 10mm 2.53.3V 85W Direct Digital Amplification
PDF
/
Buying Options
Total Price: USD $3.22
Unit Price: USD $3.2224
≥1 USD $3.2224
≥10 USD $2.64385
≥100 USD $2.5612
≥500 USD $2.47855
≥1000 USD $2.3959
Inventory: 1459
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 10mm
Length 10mm
Height Seated (Max) 1.6mm
Technical
Number of Bands 2
Consumer IC Type TONE CONTROL CIRCUIT
Specifications Direct Digital Amplification
Output Power 85W
Interface I2C, I2S
Number of Channels 8
Supply Voltage-Min (Vsup) 2.3V
Power Supplies 2.53.3V
Supply Voltage-Max (Vsup) 2.7V
Qualification Status Not Qualified
Function Fully Integrated Processor
Base Part Number STA308
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.5mm
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Voltage - Supply 3V~3.6V
Technology CMOS
Subcategory Other Consumer ICs
Applications Pre-Amplifier
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 64
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e4
Series DDX?
Packaging Tray
Operating Temperature -40°C~125°C TJ
Physical
Number of Pins 64
Surface Mount YES
Package / Case 64-LQFP
Mounting Type Surface Mount
