BD37521FS-E2
RoHS
RoHS compliant
RoHS compliantPackage 24-SOP (0.213, 5.40mm Width)
Category Integrated Circuits (ICs) / Audio Special Purpose
Description
24-SOP (0.213 5.40mm Width) BICMOS Discontinued CONSUMER CIRCUIT audio circuit 10mm 8.5V -40C~85C TA
PDF
/
Buying Options
Total Price: USD $2.26
Unit Price: USD $2.26255
≥1 USD $2.26255
Inventory: 1097
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 10mm
Height Seated (Max) 2.1mm
Technical
Consumer IC Type CONSUMER CIRCUIT
Interface I2C
Number of Channels 4
Supply Voltage-Min (Vsup) 7V
Power Supplies 8.5V
Supply Voltage-Max (Vsup) 9.5V
Qualification Status Not Qualified
Function Audio Tone Processor
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.8mm
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 7V~9.5V
Technology BICMOS
Subcategory Audio Control ICs
Applications Automotive Audio, Consumer Audio
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Pbfree Code yes
Published 2010
Packaging Cut Tape (CT)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 24
Surface Mount YES
Package / Case 24-SOP (0.213, 5.40mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
