BD3484FS-E2
RoHS
RoHS compliant
RoHS compliantPackage SOT-23-6
Category Integrated Circuits (ICs) / Audio Special Purpose
Description
Copper Tin GULL WING DUAL On/Off audio circuit 150C 8.5V 250mA 5.4mm
PDF
/
Buying Options
Total Price: USD $13.25
Unit Price: USD $13.248474
≥1 USD $13.248474
≥200 USD $5.287048
≥500 USD $5.109807
≥1000 USD $5.023155
Inventory: 1438
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Plating Copper, Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SOT-23-6
Number of Pins 32
Technical
Packaging Tape & Reel (TR)
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 32
ECCN Code EAR99
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Subcategory Other Consumer ICs
Technology BICMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 0.8mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number BD3484
Pin Count 32
Number of Outputs 2
Qualification Status Not Qualified
Max Output Current 250mA
Supply Voltage-Max (Vsup) 9.5V
Power Supplies 8.5V
Temperature Grade INDUSTRIAL
Supply Voltage-Min (Vsup) 7V
Number of Channels 4
Interface On/Off
Consumer IC Type TONE CONTROL CIRCUIT
Number of Bands 3
Dimensions
Height Seated (Max) 1.9mm
Length 13.6mm
Width 5.4mm
Compliance
RoHS Status ROHS3 Compliant
