MAX13326GUI/V+
RoHS
RoHS compliant
RoHS compliantPackage 28-TSSOP (0.173, 4.40mm Width) Exposed Pad
Category Integrated Circuits (ICs) / Audio Special Purpose
Description
MAX13326 e3 Automotive AEC-Q100 28-TSSOP (0.173 4.40mm Width) Exposed Pad audio circuit 0.635mm 1.7mA 14.4V Class D
PDF
/
Buying Options
Total Price: USD $12.08
Unit Price: USD $12.0821
≥1 USD $12.0821
≥10 USD $9.91325
≥100 USD $9.60355
≥500 USD $9.29385
≥1000 USD $8.98415
Inventory: 1279
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 28-TSSOP (0.173, 4.40mm Width) Exposed Pad
Technical
Operating Temperature -40°C~105°C TA
Packaging Tube
Published 2012
Series Automotive, AEC-Q100
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Applications Automotive Audio, Pre-Amplifier, Professional Audio
Technology BCDMOS
Voltage - Supply 4.5V~18V
Terminal Position DUAL
Terminal Form GULL WING
Supply Voltage 14.4V
Terminal Pitch 0.635mm
Base Part Number MAX13326
Function Line Driver
Power Supplies 14.4V
Interface I2C
Nominal Supply Current 1.7mA
Differential Output YES
Specifications Class D
Driver Number of Bits 2
Number of Output Lines 2
Out Swing-Min 8.4 V
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
