EXB-24ATAAR5X
RoHS
RoHS compliant
RoHS compliantPackage 0404 (1010 Metric), Concave
Category RF/IF and RFID / Attenuators
Description
RF ATTENUATOR 10DB 50OHM 0404
PDF
/
Buying Options
Total Price: USD $0.14
Unit Price: USD $0.1408
≥1 USD $0.1408
≥10 USD $0.12672
≥100 USD $0.1144
≥500 USD $0.100144
≥1000 USD $0.087894
≥3000 USD $0.077669
Inventory: 1816
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 1mm
Height 350μm
Technical
Attenuation Value 10dB
Input Power-Max (CW) 16.02dBm
VSWR-Max 1.3
RF/Microwave Device Type FIXED ATTENUATOR
Frequency Range 0Hz~3GHz
Impedance 50Ohm
Number of Elements 3
Frequency 3GHz
Construction COMPONENT
Max Power Dissipation 40mW
Power Rating 40mW
Composition Thick Film
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Temperature Coefficient 200 ppm/°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2011
Packaging Tape & Reel (TR)
Physical
Number of Pins 4
Package / Case 0404 (1010 Metric), Concave
Mount Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 12 Weeks
