EXB-24ABAG2RX
RoHS
/
Package 0404 (1010 Metric), Concave
Category RF/IF and RFID / Attenuators
Description
ATTENUATOR 10DB 300 OHM 0404 SMD
PDF
/
Inventory: 5875
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Width 1mm
Height 350μm
Technical
Attenuation Value 10dB
Input Power-Max (CW) 16.02dBm
VSWR-Max 1.5
Operating Frequency-Max 2500MHz
RF/Microwave Device Type FIXED ATTENUATOR
Frequency Range 0Hz~2.5GHz
Max Frequency 2.5GHz
Impedance 300Ohm
Operating Temperature (Min) -55°C
Operating Temperature (Max) 70°C
Construction COMPONENT
Max Power Dissipation 40mW
Power Rating 40mW
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2007
Packaging Tape & Reel (TR)
Physical
Number of Pins 4
Package / Case 0404 (1010 Metric), Concave
