HMC1019ALP4E
RoHS
RoHS compliant
RoHS compliantPackage 24-VFQFN Exposed Pad
Category RF/IF and RFID / Attenuators
Description
Attenuators 0.5 dB LSB 5-Bit dig atten 0.1-30 GHz
PDF
/
Buying Options
Total Price: USD $137.47
Unit Price: USD $137.4736
≥1 USD $137.4736
≥10 USD $129.14
≥100 USD $122.891296
Inventory: 105
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Technical
Insertion Loss (Max) 6.5 dB
Attenuation Value 15.5dB
Characteristic Impedance 50Ohm
Input Power-Max (CW) 27dBm
Operating Frequency-Min 100MHz
Operating Frequency-Max 30000MHz
RF/Microwave Device Type VARIABLE ATTENUATOR
Frequency Range 100MHz~30GHz
Supply Current-Max 6.5mA
Power Supplies +-5V
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Pin Count 24
Base Part Number HMC1019
Construction COMPONENT
Technology GAAS
Additional Feature CMOS COMPATIBLE
Number of Terminations 24
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code no
Packaging Strip
Physical
Number of Pins 24
Mounting Feature SURFACE MOUNT
Surface Mount YES
Package / Case 24-VFQFN Exposed Pad
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 weeks ago)
Factory Lead Time 8 Weeks
