CL-50-100
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Arrays, Signal Transformers
Description
INDUCT ARRAY 2COIL 120UH CHA MNT
PDF
/
Buying Options
Total Price: USD $134.08
Unit Price: USD $134.0768
≥1 USD $134.0768
Inventory: 34
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 95.3008mm
Length 114.3mm
Height 3.752 95.30mm
Technical
Inductance - Connected In Parallel 120μH
Inductance - Connected In Series 500μH
Current Rating - Parallel 100A
Current Rating - Series 50A
DC Resistance (DCR) - Series 4.3mOhm
Number of Coils 2
Inductance - Series 500 μH
Inductance - Parallel 120 μH
DC Resistance (DCR) - Parallel 1.1mOhm
Current 50A
Shielding Unshielded
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Size / Dimension 4.500Lx3.752W 114.30mmx95.30mm
Series CL
Published 2009
Packaging Bulk
Physical
Package / Case Nonstandard
Mounting Type Chassis Mount
Mount Chassis Mount
Supply Chain
Factory Lead Time 16 Weeks
