PF0553.154NLT
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Arrays, Signal Transformers
Description
Active PARALLEL CONNECTED e3 WRAPAROUND signal transformer -40C~125C ±20% 250mOhm Max 0.315 8.00mm
PDF
/
Inventory: 4178
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height 0.315 8.00mm
Technical
Current Saturation - Series 1.5A
Current Saturation - Parallel 3A
Inductance - Connected In Parallel 150μH
Current Rating - Parallel 1.6A
DC Resistance (DCR) - Series 990mOhm Max
Number of Coils 2
Inductance - Series 600 μH
Inductance - Parallel 150 μH
Special Feature PARALLEL CONNECTED
DC Resistance (DCR) - Parallel 250mOhm Max
Inductor Type GENERAL PURPOSE INDUCTOR
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
Max DC Current 1.6A
Current 780mA
Inductance 150 μH
Number of Functions 2
Shielding YES
HTS Code 8504.50.80.00
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Tolerance ±20%
Size / Dimension 0.492Lx0.492W 12.50mmx12.50mm
Series PF0553NL
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Alternative Model
