PF0552.822NLT
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Arrays, Signal Transformers
Description
Active PARALLEL CONNECTED e3 WRAPAROUND signal transformer -40C~125C ±20% 0.1MHz 18mOhm Max
PDF
/
Inventory: 7412
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height 0.236 6.00mm
Technical
Current Saturation - Series 3.9A
Current Saturation - Parallel 7.8A
Inductance - Connected In Parallel 8.1μH
Current Rating - Parallel 6.5A
DC Resistance (DCR) - Series 66mOhm Max
Number of Coils 2
Inductance - Series 32 μH
Inductance - Parallel 8.1 μH
Special Feature PARALLEL CONNECTED
DC Resistance (DCR) - Parallel 18mOhm Max
Inductor Type GENERAL PURPOSE INDUCTOR
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
Max DC Current 6.5A
Current 3.3A
Test Frequency 0.1MHz
Inductance 32 μH
Number of Functions 2
Shielding YES
HTS Code 8504.50.80.00
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Tolerance ±20%
Size / Dimension 0.492Lx0.492W 12.50mmx12.50mm
Series PF0552NL
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
