PF0552.473NLT
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Arrays, Signal Transformers
Description
Active PARALLEL CONNECTED WRAPAROUND RoHS Compliant Signal Transformer -40C~125C ±20% 100kHz 69mOhm Max
PDF
/
Inventory: 8599
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series PF0552NL
Size / Dimension 0.492Lx0.492W 12.50mmx12.50mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
Termination SMD/SMT
ECCN Code EAR99
HTS Code 8504.50.80.00
Shielding YES
Number of Functions 2
Depth 12.5mm
Military Standard Not
Inductance 47 μH
Test Frequency 100kHz
Current 1.7A
Max DC Current 3.2A
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Inductor Type GENERAL PURPOSE INDUCTOR
DC Resistance (DCR) - Parallel 69mOhm Max
DC Current 3.2A
Special Feature PARALLEL CONNECTED
Inductance - Parallel 47 μH
Inductance - Series 190 μH
Number of Coils 2
DC Resistance (DCR) - Series 270mOhm Max
Current Rating - Parallel 3.2A
Current Saturation - Series 1.6A
Dimensions
Height 0.236 6.00mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Alternative Model
