P0401NLT
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Arrays, Signal Transformers
Description
Tomcat Nonstandard 0.715Lx0.590W 18.16mmx14.99mm 18muH
PDF
/
Inventory: 7065
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape ONE SURFACE
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -40°C~130°C
Packaging Tape & Reel (TR)
Published 2007
Series Tomcat
Size / Dimension 0.715Lx0.590W 18.16mmx14.99mm
Tolerance ±20%
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
Termination SMD/SMT
ECCN Code EAR99
HTS Code 8504.50.80.00
Packing Method TR
Shielding NO
Number of Functions 2
Depth 14.99mm
Construction Toroidal
Military Standard Not
Inductance 18 μH
Current 2.2A
Max DC Current 4.4A
Inductor Application POWER INDUCTOR
Terminal Placement DUAL IN-LINE
Inductor Type GENERAL PURPOSE INDUCTOR
Case/Size Code 7159
DC Resistance (DCR) - Parallel 38.15mOhm
DC Current 4.4A
Special Feature PARALLEL CONNECTED
Inductance - Parallel 18 μH
Inductance - Series 72 μH
Number of Coils 2
DC Resistance (DCR) - Series 152.6mOhm
Inductance - Connected In Series 109.8μH
Inductance - Connected In Parallel 27.4μH
Dimensions
Height 0.310 7.87mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Alternative Model
