P0397NL
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Arrays, Signal Transformers
Description
Tomcat Nonstandard 0.715Lx0.590W 18.16mmx14.99mm 4.2muH
PDF
/
Buying Options
Total Price: USD $2.57
Unit Price: USD $2.5696
≥1 USD $2.5696
≥10 USD $2.14632
≥100 USD $1.959936
≥500 USD $1.679744
≥1000 USD $1.539824
≥3000 USD $1.493184
Inventory: 1207
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Height 0.310 7.87mm
Technical
Inductance - Connected In Parallel 5.9μH
Inductance - Connected In Series 23.7μH
DC Resistance (DCR) - Series 41.9mOhm
Number of Coils 2
Inductance - Series 17 μH
Inductance - Parallel 4.2 μH
Special Feature PARALLEL CONNECTED
DC Current 8.2A
DC Resistance (DCR) - Parallel 10.47mOhm
Case/Size Code 7159
Inductor Type GENERAL PURPOSE INDUCTOR
Terminal Placement DUAL IN-LINE
Inductor Application POWER INDUCTOR
Max DC Current 8.2A
Current 4.1A
Inductance 4.2 μH
Military Standard Not
Construction Toroidal
Depth 14.99mm
Number of Functions 2
Shielding NO
HTS Code 8504.50.80.00
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Tolerance ±20%
Size / Dimension 0.715Lx0.590W 18.16mmx14.99mm
Series Tomcat
Published 2007
Packaging Tube
Operating Temperature -40°C~130°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Terminal Shape ONE SURFACE
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
