DRQ73-331-R
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Arrays, Signal Transformers
Description
DRQ Nonstandard 0.299Lx0.299W 7.60mmx7.60mm 330muH
PDF
/
Buying Options
Total Price: USD $0.8
Unit Price: USD $0.798658
≥1 USD $0.798658
Inventory: 4052
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Number of Pins 4
Weight 907.18474mg
Core Material Ferrite
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2014
Series DRQ
Size / Dimension 0.299Lx0.299W 7.60mmx7.60mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Resistance 1.59Ohm
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Shielding Shielded
Depth 7.6mm
Military Standard Not
Inductance 330 μH
Test Frequency 100kHz
Current 211mA
Max DC Current 440mA
DC Resistance (DCR) - Parallel 1.59Ohm
Inductance - Parallel 325.5 μH
Inductance - Series 1.3 mH
Number of Coils 2
DC Resistance (DCR) - Series 6.36Ohm
Current Rating - Series 211mA
Current Rating - Parallel 420mA
Inductance - Connected In Series 1.302mH
Inductance - Connected In Parallel 325.5μH
Current Saturation - Parallel 440mA
Current Saturation - Series 220mA
Dimensions
Height 0.140 3.55mm
Length 7.5946mm
Width 7.5946mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
