CTX68-4A-R
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Arrays, Signal Transformers
Description
OCTA-PAC? PLUS Nonstandard 0.550Lx0.550W 13.97mmx13.97mm 68muH
PDF
/
Inventory: 4248
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 13.97mm
Length 13.97mm
Height 0.250 6.35mm
Technical
Current Saturation - Series 800mA
Current Saturation - Parallel 1.61A
Inductance - Connected In Parallel 68.21μH
Inductance - Connected In Series 272.8μH
Current Rating - Parallel 1.7A
Current Rating - Series 850mA
DC Resistance (DCR) - Series 612mOhm Max
Number of Coils 2
Inductance - Series 272.8 μH
Inductance - Parallel 68.21 μH
DC Resistance (DCR) - Parallel 153mOhm Max
Max DC Current 1.61A
Current 850mA
Inductance 68 μH
Shielding Unshielded
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Resistance 153mOhm
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±25%
Size / Dimension 0.550Lx0.550W 13.97mmx13.97mm
Series OCTA-PAC? PLUS
Published 2007
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Core Material Metal
Weight 2.267962g
Number of Pins 4
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 15 Weeks
