CTX5-2P-R
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Arrays, Signal Transformers
Description
Econo-Pac? Nonstandard 0.450Lx0.450W 11.43mmx11.43mm 4.9muH
PDF
/
Inventory: 1339
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 11.43mm
Length 11.43mm
Height 0.235 5.97mm
Technical
Inductance - Connected In Parallel 4.9μH
Inductance - Connected In Series 19.58μH
Current Rating - Parallel 2.5A
Current Rating - Series 1.25A
DC Resistance (DCR) - Series 128mOhm Max
Number of Coils 2
Inductance - Series 19.58 μH
Inductance - Parallel 4.9 μH
DC Resistance (DCR) - Parallel 32mOhm Max
Max DC Current 2.5A
Current 1.25A
Test Frequency 100kHz
Inductance 4.9 μH
Military Standard Not
Depth 11.43mm
Shielding Unshielded
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Resistance 32mOhm
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.450Lx0.450W 11.43mmx11.43mm
Series Econo-Pac?
Published 2007
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Core Material Ferrite
Weight 1.814369g
Number of Pins 4
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
