CTX25-1-R
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Arrays, Signal Transformers
Description
OCTA-PAC? Nonstandard 0.450Lx0.450W 11.43mmx11.43mm 25.6muH
PDF
/
Inventory: 4559
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Number of Pins 4
Weight 1.360777g
Core Material Metal
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2007
Series OCTA-PAC?
Size / Dimension 0.450Lx0.450W 11.43mmx11.43mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Resistance 167mOhm
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Shielding Unshielded
Inductance 25.6 μH
Current 370mA
Max DC Current 740mA
DC Resistance (DCR) - Parallel 167mOhm Max
Inductance - Parallel 25.6 μH
Inductance - Series 102.4 μH
Number of Coils 2
DC Resistance (DCR) - Series 668mOhm Max
Current Rating - Series 370mA
Current Rating - Parallel 740mA
Inductance - Connected In Series 102.4μH
Inductance - Connected In Parallel 25.6μH
Dimensions
Height 0.165 4.19mm
Length 11.43mm
Width 11.43mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
