RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Arrays, Signal Transformers
Description Obsolete Non-RoHS Compliant Surface Mount 2004 Array -40C~85C ±20% 84mOhm Max 0.250 6.35mm
PDF
/
Inventory: 9019
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant

Dimensions

Height 0.250 6.35mm

Technical

Inductance - Connected In Parallel 20.62μH
Inductance - Connected In Series 82.47μH
Current Rating - Parallel 1.9A
Current Rating - Series 950mA
DC Resistance (DCR) - Series 337mOhm Max
Number of Coils 2
DC Resistance (DCR) - Parallel 84mOhm Max
Shielding Unshielded
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Tolerance ±20%
Size / Dimension 0.550Lx0.550W 13.97mmx13.97mm
Series Econo-Pac?
Published 2004
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C

Physical

Package / Case Nonstandard
Mounting Type Surface Mount
