CTX100-2
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Arrays, Signal Transformers
Description
Unshielded 2 Coil Inductor Array 397.81μH Inductance - Connected in Series 99.45μH Inductance - Connected in Parallel 457mOhm Max DC Resistance (DCR) - Parallel 630mA Nonstandard
PDF
/
Buying Options
Total Price: USD $0.97
Unit Price: USD $0.96805
≥1 USD $0.96805
≥10 USD $0.7942
≥100 USD $0.7695
≥500 USD $0.7448
≥1000 USD $0.7201
Inventory: 37003
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Height 0.235 5.97mm
Technical
Inductance - Connected In Parallel 99.45μH
Inductance - Connected In Series 397.81μH
Current Rating - Parallel 630mA
Current Rating - Series 320mA
DC Resistance (DCR) - Series 1.828Ohm Max
Number of Coils 2
DC Resistance (DCR) - Parallel 457mOhm Max
Shielding Unshielded
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Tolerance ±20%
Size / Dimension 0.450Lx0.450W 11.43mmx11.43mm
Series OCTA-PAC?
Published 1997
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Package / Case Nonstandard
Mounting Type Surface Mount
Alternative Model
