CTX0.68-4-R image
Favorite
CTX0.68-4-R image
Favorite
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Arrays, Signal Transformers
Description OCTA-PAC? Nonstandard 0.550Lx0.550W 13.97mmx13.97mm 67.08muH
PDF
/
Inventory: 5431
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 15 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Number of Pins 4
Weight 453.59237mg
Core Material Metal

Technical

Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series OCTA-PAC?
Size / Dimension 0.550Lx0.550W 13.97mmx13.97mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Resistance 5mOhm
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Shielding Unshielded
Depth 13.97mm
Inductance 67.08 μH
Current 3A
Max DC Current 6A
DC Resistance (DCR) - Parallel 5mOhm Max
Inductance - Parallel 780 nH
Inductance - Series 3.14 μH
Number of Coils 2
DC Resistance (DCR) - Series 20mOhm Max
Current Rating - Series 3A
Current Rating - Parallel 6A
Inductance - Connected In Series 3.14μH
Inductance - Connected In Parallel 780nH

Dimensions

Height 0.250 6.35mm
Length 13.97mm
Width 13.97mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
