SRF1260A-681M
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Arrays, Signal Transformers
Description
SRF1260A Nonstandard 0.492Lx0.492W 12.50mmx12.50mm 680muH
PDF
/
Inventory: 3165
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Core Material Ferrite
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2013
Series SRF1260A
Size / Dimension 0.492Lx0.492W 12.50mmx12.50mm
Tolerance ±20%
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
ECCN Code EAR99
Resistance 1.212Ohm
Terminal Finish Tin (Sn)
Composition Wirewound
HTS Code 8504.50.80.00
Shielding Shielded
Depth 12.5mm
Current Rating 700mA
Military Standard Not
Inductance 680 μH
Test Frequency 100kHz
Max DC Current 425mA
Inductor Type GENERAL PURPOSE INDUCTOR
DC Resistance (DCR) - Parallel 1.212Ohm Max
RMS Current (Irms) 700mA
Inductance - Parallel 680 μH
Inductance - Series 2.72 mH
Number of Coils 2
DC Resistance (DCR) - Series 4.635Ohm Max
Current Rating - Series 350mA
Inductance - Connected In Series 2.72mH
Saturation Current 850mA
Dimensions
Height 0.244 6.20mm
Height Seated (Max) 6.1976mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Ratings AEC-Q200
