SRF0703A-470M
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Arrays, Signal Transformers
Description
SRF0703A Nonstandard 0.299Lx0.299W 7.60mmx7.60mm 47muH
PDF
/
Buying Options
Total Price: USD $0.71
Unit Price: USD $0.7128
≥1 USD $0.7128
≥10 USD $0.60456
≥100 USD $0.549824
≥500 USD $0.516912
≥1000 USD $0.429
≥3000 USD $0.396
Inventory: 1070
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Weight 879.997547mg
Core Material Ferrite
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2014
Series SRF0703A
Size / Dimension 0.299Lx0.299W 7.60mmx7.60mm
Tolerance ±20%
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
ECCN Code EAR99
Resistance 338mOhm
Terminal Finish Tin (Sn)
HTS Code 8504.50.80.00
Shielding Shielded
Inductance 47 μH
Max DC Current 1.08A
Inductor Type GENERAL PURPOSE INDUCTOR
DC Resistance (DCR) - Parallel 338mOhm Max
RMS Current (Irms) 1.08A
Inductance - Parallel 47 μH
Inductance - Series 194.2 μH
Number of Coils 2
DC Resistance (DCR) - Series 1.28Ohm Max
Current Rating - Series 542mA
Current Saturation - Parallel 1.14A
Current Saturation - Series 570mA
Dimensions
Height 0.142 3.60mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Ratings AEC-Q200
